February 06, 2019 2 min read

2020 Ford Super Duty 6.7L Engine Specs

2020 Powerstroke 6.7 changes

INTRODUCTION

For the current model year, the 6.7-liter Power Stroke pushes out 450 hp and 935 lb.-ft. of torque. It has grown from the generation 1 6.7’s 400 hp / 800 lb.-ft.

After talking with our contact at Ford here is what we at SPE can tell you. Please be advised, this is only speculation from a reliable source.



POWER NUMBERS

The power numbers for 2020 will be made available closer to the launch although we were given an inside number on the improvement.



AIR & FUEL

The updated 2020 Power Stroke includes a new 36,000-psi fuel injection system with all-new injectors which can precisely meter and spray up to eight times per stroke to control noise levels and optimize combustion, essentially adding more pilot injection cycles. This will leave more on the table for power enhancement in an aftermarket aspect.The engine features a redesigned VGT turbocharger for improved efficiency and throttle response. We won't know the actual sizing until we tear one down. What we did find out via Mike Pruitt, is the new turbo will have an electronically actuated VGT system and a wastegate is also a possibility. It is also worth noting that the new injector nozzles/fuel system modifications and exhaust improvements will squeeze out an estimated 40 more horsepower and 80 more lb. ft. of torque. So, from an estimation standpoint the 2020 6.7 should have an output of490hp and 1015 lb.-ftof torque setting it in a class of its own. It just may eclipse the 500hp number.



ENGINE & INTERNALS

Structural enhancements for the 2020 engine increase the strength of the cylinder head, block, connecting rods and bearings to handle the higher cylinder pressure and increased output.

New steel pistons provide higher firing pressure capability and less friction for added performance, all helping with horsepower and torque. It’s to be a short height piston (less friction), long rod design. Thus, this will aid in helping rod angle and keeping the piston mass as low as possible due to the material change.

2020 Powerstroke Steel Piston

The cylinder head casting has been revised for better cooling, including modified passages. The low pressure oil system and front cover has also been changed for more efficiency and overall wear aspects. The lower intake manifold is now a two piece design to better deal with thermal efficiency, and the non-pressure side (turbo inlet to air filter) is now composite. The pressure side of the intake manifold system including the upper intake is now cast aluminum.

2020 Powerstroke 6.7L engine

2020 Powerstroke Engine changes



CONCLUSION

The 2020 Ford Super Duty Powerstroke will be breaking some new ground and continue to interrupt the OEM landscape. With the new design, we SPE will continue to push forward and develop the best parts on the market. After all, we are enthusiasts just like you.



Learn more button



Interested in learning more about the 2020? Check out a video of an engine teardown here.
